Product details
Product Description
The WK-115 Vacuum Pump is a compact and reliable single-stage HVAC vacuum pump designed for light-duty evacuation of air conditioning and refrigeration systems. With a 1.8 CFM flow rate, it is ideal for small systems and routine servicing tasks.
This model features a simple and efficient design, making it a cost-effective choice for technicians who need dependable performance without advanced components. The copper motor ensures stable operation, while the oil mist filter helps maintain cleaner working conditions.
Its compact and lightweight construction makes it easy to carry, making it especially suitable for field service and mobile technicians.
Key Features
- Single-stage vacuum pump for standard HVAC applications
- 1.8 CFM (42 L/min) flow rate for small system evacuation
- Compact and lightweight design for portability
- Durable copper motor for reliable performance
- Oil mist filter for cleaner operation
- Large oil sight glass for easy monitoring
- Brass inlet port for durability
- Simple and cost-effective solution for technicians
Technical Specifications
| Specification | Details |
|---|---|
| Model | WK-115 |
| Type | Vacuum Pump |
| Stage | Single Stage |
| Flow Rate | 1.8 CFM (42 L/min @ 50Hz) |
| Flow Rate (60Hz) | 2.0 CFM (50–60 L/min) |
| Ultimate Vacuum | 150 microns |
| Power | 1/4 HP |
| Inlet Port | 1/4″ Flare |
| Oil Capacity | ~230 ml |
| Dimensions | 290 × 124 × 227 mm |
| Weight | Approx. 5.2 kg |
Applications
- Small HVAC system evacuation
- Split AC installation and servicing
- Refrigeration maintenance
- Removal of air and moisture from systems
- Field service operations
Frequently Asked Questions (FAQs)
Q1: Is WK-115 single or dual stage?
It is a single-stage vacuum pump.
Q2: What is its capacity?
It provides 1.8 CFM flow rate at 50Hz.
Q3: Is it suitable for large systems?
No, it is best for small HVAC and residential applications.
Q4: What is the vacuum level?
It achieves up to 150 microns.
Q5: Is it portable?
Yes, its compact size and lightweight design make it easy to carry.
