Product details
Product Description
The Danfoss MTZ32JF5AVE is a hermetic reciprocating compressor designed for medium and high temperature refrigeration applications. Manufactured under the Danfoss MTZ series, it delivers reliable cooling performance, energy efficiency, and long service life for commercial refrigeration systems.
Built with proven reciprocating compressor technology, the MTZ32JF5AVE is compatible with multiple refrigerants including R134a, R404A, R407A, R407C, R407F, R448A, R449A, R452A, R454C, R455A, and R513A. Its robust hermetic construction and internal motor protection help ensure dependable operation under demanding conditions.
Operating on a 220-240V single-phase 50Hz power supply, the compressor utilizes POE 175PZ oil lubrication and fixed-speed technology for stable and efficient performance. It is suitable for cold rooms, display refrigerators, beverage coolers, and various commercial refrigeration systems.
Key Features
. Hermetic reciprocating compressor design
. Suitable for medium and high temperature refrigeration applications
. Compatible with multiple refrigerants
. Single-phase operation for easy installation
. Internal overload motor protection
. Fixed-speed compressor technology
. POE 175PZ oil lubrication
. Reliable performance for commercial refrigeration systems
. Durable hermetic construction
. Suitable for continuous-duty operation
Technical Specifications
General Information
Model: MTZ32JF5AVE
Part Number: MTZ32-5VM
Brand: Danfoss
Product Type: Compressor
Compressor Type: Hermetic Reciprocating
Series: MTZ
Application: Medium & High Temperature Refrigeration
Refrigerant: R134a, R404A, R407A, R407C, R407F, R448A, R449A, R452A, R454C, R455A, R513A
Electrical Data
. Voltage: 220-240V
. Frequency: 50Hz
. Phase: 1Ph
. RLA: Data Required
. LRA: 70 A
. MCC: 20 A
. Motor Protection: Internal Overload Protector
Performance Data
. Cooling Capacity: 3.98 kW
. Swept Volume: 53.86 cm³
. Technology: Reciprocating
. EER: Data Required
. COP: Data Required
Mechanical Data
. Oil Type: POE 175PZ
. Oil Charge: 0.95 L
. Displacement: 53.86 cm³
. Suction Connection: 1-1/4″ Rotolock
. Discharge Connection: 1″ Rotolock
. Weight: 25 KG
Operating Data
. Operating Range: Medium & High Temperature Refrigeration
. Maximum Refrigerant Charge: 2.5 kg
. Maximum High Side Pressure: 29.4 bar
. Maximum Low Side Pressure: 22.6 bar
. Protection Class: IP55
Product Identification
. Model Number: MTZ32JF5AVE
. Part Number: MTZ32-5VM
Frequently Asked Questions (FAQ)
Q: What refrigerants are approved for the MTZ32JF5AVE?
A: The compressor is approved for R134a, R404A, R407A, R407C, R407F, R448A, R449A, R452A, R454C, R455A, and R513A refrigerants.
Q: Is this compressor single-phase?
A: Yes, it operates on 220-240V single-phase 50Hz power supply.
Q: What oil does this compressor use?
A: The compressor uses POE 175PZ oil with a factory oil charge of 0.95 liters.
Q: What type of compressor is MTZ32JF5AVE?
A: It is a hermetic reciprocating compressor designed for refrigeration applications.
Q: Does the compressor include motor protection?
A: Yes, it features an internal overload protector.
