CAMRegis Data Logger Remote Channel 15724 AKO

The CAMRegis Data Logger Remote Channel AKO-15724 is built for accurate monitoring and recording of environmental and process parameters in refrigeration, HVAC, and industrial installations. The device supports multiple probe types and provides dependable alarm signaling along with secure data storage for long-term monitoring.

Its wall-mounted design allows easy installation while continuous logging helps technicians track performance and respond quickly to abnormal conditions. Integrated alarm relay and buzzer functions ensure alerts are delivered whenever configured limits are exceeded.

Key Benefits

Dual channels allow monitoring of multiple parameters simultaneously
Compatible with NTC, mA, and digital input probes for flexible installation
Built-in buzzer provides immediate alarm notification
Alarm relay enables connection to external warning or control systems
Wall-mounted design allows fast and clean installation
Accurate data recording supports maintenance and compliance tracking
SD card and USB reader allow easy data retrieval
Designed for reliable long-term monitoring operation

Specifications

Brand: AKO
Product Name: CAMRegis Data Logger Remote Channel
Model: AKO-15724
Mounting Type: Wall-mounted version
Dimensions: 174 × 94 × 42 mm
Inputs: 2 channels
Probe Compatibility: NTC / mA / Digital Input
Display: 3½ digit display
Accuracy: ±1%
Buzzer: Internal buzzer included
Protection Rating: IP40
Relay Output: 1 CO-8A(4) relay
Alarm Outputs: 1
Alarm Relay: CO-8A(4)
Voltage Type: AC
Supply Voltage: 220–240 VAC
Measuring Range: Depends on connected probe
Scope of Delivery: NTC probe, SD card, USB reader included

Applications

Cold room and refrigeration monitoring
HVAC performance logging and diagnostics
Warehouse and storage monitoring systems
Industrial process condition tracking
Commercial facility alarm and data supervision

FAQs

Can two sensors be connected at the same time?
Yes, the device supports two independent input channels.

How is recorded data accessed?
Data is stored on the included SD card and can be transferred using the supplied USB reader.

Does the unit support alarm connections?
Yes, it provides both an internal buzzer and alarm relay output.

Is it suitable for industrial environments?
Yes, it is designed for commercial and industrial monitoring applications.

Short Description (Repeat)

CAMRegis Data Logger Remote Channel AKO-15724 provides dual-channel monitoring, alarm signaling, and data logging, making it ideal for HVAC, refrigeration, and industrial monitoring systems requiring reliable performance.
