Danfoss BN240CS Solenoid Coil | 208-240V AC | Terminal Box | 018F6832

Product Description: The BN240CS (018F6832) is a “Heavy Duty” variant designed to handle voltage ranges from 208V to 240V AC (50/60Hz). This makes it exceptionally versatile for the UAE market, where it can easily accommodate both standard 230V residential grids and 208V industrial/commercial supplies. The “BN” series is particularly noted for its high resistance to humidity and extreme temperatures. In the UAE—where rooftop plant rooms and seaside installations face intense salt-laden humidity—the IP67-rated terminal box provides an airtight seal for electrical connections, preventing short circuits and corrosion that often plague standard coils.

Key Features & Benefits:

• Wide Voltage Range: Optimized for both 208V and 240V applications, providing stable operation despite voltage fluctuations.
• Superior Moisture Resistance: The BN series is designed for “wet” environments, making it ideal for the high humidity of Dubai and the Northern Emirates.
• Class H Insulation: Rated to withstand temperatures up to 180°C, ensuring the coil does not degrade during the peak of the UAE summer.
• Secure Terminal Box: Offers IP67 protection, ensuring that the electrical terminals remain dry and free from dust and debris.
• Tool-Free Clip-on System: Allows for rapid installation or replacement onto the valve actuator without needing to open the refrigeration circuit.

Technical Specifications:

FAQs:

• Q: Can I use the 018F6832 for outdoor AC units in Jebel Ali?
• A: Yes. Its IP67 rating and heavy-duty winding make it perfect for industrial zones where dust and high temperatures are constant.
• Q: What is the main difference between BN and BG coils?
• A: The BN series (like 018F6832) typically has a higher power rating (20W) compared to the standard BG (12W), allowing for more reliable valve opening in high-pressure differential applications.
• Q: Does it fit all EVR valves?
• A: It fits the standard Danfoss “Clip-on” range from EVR 2 to EVR 40.
