Product details
Danfoss OD S Oil Nozzle | 2.00 gal/h | 60° Spray Angle | Solid Pattern
Product Description:
The Danfoss 030F6132 (OD S) is the professional choice for high-capacity oil burners throughout the UAE. Delivering a substantial flow rate of 2.00 gal/h (7.42 kg/h), this nozzle provides the intensive heat output required for large industrial steam generators and massive commercial boiler plants in Dubai. The 60° solid (S) spray pattern is designed to produce a stable and concentrated flame core, ensuring optimal atomization and complete combustion even at higher fuel pressures. Every nozzle is meticulously tested to Danfoss’s global standards, ensuring that UAE plant operators can achieve peak thermal efficiency while minimizing soot and carbon emissions. Its industrial-grade construction is built to endure the rigorous continuous-duty cycles typical of major infrastructure projects in the Middle East.
Key Features & Benefits:
- High-Capacity Heating: 2.00 gal/h rating is perfect for the large-scale energy requirements of UAE industrial facilities.
- Focused Solid Pattern: 60° solid spray maintains a consistent flame geometry, even in high-velocity combustion chambers in Dubai.
- Engineered for Efficiency: Advanced atomization technology helps UAE facilities reduce fuel consumption and environmental impact.
- Strict Quality Control: 100% electronic testing of spray symmetry and flow rate ensures reliability for UAE maintenance teams.
- Robust Construction: Designed to resist the high temperatures and pressures of modern UAE burner systems.
Technical Specifications (Table):
| Specifications | Value |
| Manufacturer | Danfoss |
| Product Model | OD Series (Type S) |
| Code Number | 030F6132 |
| Flow Rate (US gal/h) | 2.00 gal/h |
| Flow Rate (kg/h) | 7.42 kg/h |
| Spray Angle | 60° |
| Spray Pattern | Solid (S) |
| Media Compatibility | Heavy & Light Heating Oils / Fuel Oil |
FAQs:
- Q: Is the 2.00 gal/h nozzle (030F6132) used in UAE district heating?
- A: Yes, it is a common specification for the high-output boilers used in large-scale UAE residential and commercial complexes.
- Q: Why is a solid pattern preferred for high-flow nozzles in Dubai?
- A: In high-capacity burners, a solid pattern (S) provides a more stable flame core that is less susceptible to turbulence within the large combustion chambers used in the UAE.
- Q: How does this nozzle contribute to sustainability in the UAE?
- A: By ensuring near-perfect atomization, it minimizes unburnt fuel and soot, helping UAE companies meet stricter emission standards in Dubai.
